About Anticyclone Systems Ltd

Company background

Anticyclone Systems Ltd, founded in 1998, is a established design house combining a unique blend of skills to bring innovative, tightly coupled hardware and software solutions to the marketplace. We are proud of our proven ability to deliver highly competitive products world-wide and have built a reputation for delivering our products within tight time scales.

The unique combination of hardware and software expertise available to us is our key to success. Anticyclone Systems Ltd is currently focused on the RS232 data logging market. Our AntiLogPro product is an excellent example of a tightly coupled design which gives world class performance coupled with low power consumption.

In the past, we have supplied software solutions and microcontroller based systems to meet individual customer requirements. Examples include our WxWatch real time weather satellite image reception system for the UK Royal Navy, a digital radiosonde meteorological measurement system and a custom X-Y antenna tracking motor control system for satellite ground stations.

Anticyclone Systems Limited is a company registered in England and Wales
Registration number
V.A.T. registration
709 1722 41
Mr G Hatto
Registered office
7 Lime Avenue, Westergate, Chichester, West Sussex. PO20 3UF
Company Information required by EC Regulations, 2002 and GDPR

RS232 data logging

There are a vast range of electronic devices in the world that can output data in RS232 format. Examples include Global Positioning System (GPS) receivers, test and measurement equipment, process control systems and communication systems. There is also a sizeable requirement to log this data reliably. For example, to performing system analysis, field trials data recording, or equipment verification and validation.

AntiLog Boxed AntiLog OEM
AntiLogPro Boxed AntiLogPro OEM

Our AntiLog product range was designed from the ground up to be this dedicated, reliable data logging solution. We have combined a powerful stand-alone microcontroller with some tightly coupled software to realise a highly portable RS232 data logging system which can write to extremely small, lightweight, solid state FLASH media.

AntiLog is now in use throughout the world in a very diverse range of applications including transport development, civil and military GPS receiver data logging, medical equipment monitoring, wildlife monitoring, unmanned aircraft flight data recording, sea trials, crop yield control, crane safety and a whole host of other process control applications.

So next time you need to log RS232 data, why not look at our AntiLog product range and see for yourself the benefits of a high quality, dedicated data recording device.

Archive: Weather satellite image reception

Compressed NOAA Image

The first major product developed by Anticyclone Systems Ltd was a professional weather satellite image reception system called WxWatch. The system was fitted to warships in the United Kingdom's Royal Navy.

The WxWatch system supported reception and processing of weather satellite imagery in real time. Core capabilities included image projection onto mapped surfaces, full overlay gridding with high resolution map overlays, automated image reception and automated image administration.

Anticyclone Systems Ltd also designed a tightly coupled, microcontroller based signal processing unit to decode the weather satellite signals which included a unique adaptive tracking filter for accurate signal tracking throughout a complete satellite pass.

Archive: Antenna Tracking Controller

SMCP Control Board

Anticyclone Systems Ltd also designed a unique servo motor control system for satellite antenna tracking. These servo motor control boards were designed to control motors in 'X-Y' head assemblies and were used in the ASCAT ground transponder systems used to command and control the METOP series of satellites.
